Vulcanite Stems
we no longer machine tenons since we now sell the tenon turning tool (listed under the tooling page)
stem lengths do not include tenons, except for the fancy where the length is the entire stem
diameter is based on the thickest part of the stem
while most sizes are accurate, some stems will vary in size
Churchwardens
Fancy
Round Taper
Round Saddle
Oval Taper
Oval Saddle
Diamond Taper
Diamond Saddle
Square Taper
Square Saddle
Grab Bag
Style | Diameter (Inches) | Length (Inches) | Stem # | Special Features |
---|---|---|---|---|
Round Taper | ||||
7/16 | 3 1/8 | 323 | Slotted P-Lip | |
3 1/16 | 7846 | |||
3 1/4 | 115 | |||
15/32 | 2 1/16 | 7004 | ||
2 7/8 | 451 | Funny Bit | ||
1/2 | 2 9/16 | 9001 | ||
2 7/8 | 577 | |||
2 15/16 | 605 | |||
3 1/16 | 179 | |||
3 5/16 | 123 | |||
3 1/2 | 163 | |||
4 7/8 | 155 | Mini Churchwarden | ||
3 | 411 | |||
17/32 | 3 | 619 | ||
3 1/16 | 453 | Funny Bit | ||
3 1/4 | 325 | Slotted P-Lip | ||
3 | 503 | |||
9/16 | 2 1/2 | 509 | ||
2 7/8 | 475 | |||
2 7/8 | 403 | Flat | ||
3 1/8 | 167 | |||
19/32 | 2 11/16 | 1076 | ||
2 13/16 | 70150 | |||
2 15/16 | 75151 | |||
3 1/8 | 189 | |||
3 1/8 | 349 | P-Lip | ||
3 5/16 | 135 | |||
3 7/16 | 145 | |||
3 5/16 | 143 | |||
5/8 | 2 1/16 | 161 | ||
2 5/8 | 165 | |||
2 3/4 | 633 | |||
3 1/8 | 617 | |||
3 3/16 | 80161 | |||
2 15/16 | 505 | |||
21/32 | 2 9/16 | 547 | ||
2 15/16 | 559 | |||
3 1/8 | 553 | |||
11/16 | 2 9/16 | 541 | ||
2 11/16 | 171 | |||
2 13/16 | 575 | |||
2 7/8 | 675 | |||
3 | 525 | |||
3 3/16 | 9201 | |||
23/32 | 3 1/8 | 517 | ||
3/4 | 3 1/4 | 535 | ||
25/32 | 2 5/8 | 175 | ||
3 3/16 | 445 | |||
27/32 | 2 15/16 | 625 | ||
29/32 | 2 5/16 | 153 | ||
3 1/2 | 187 | |||
Round Saddle | ||||
15/32 | 3 3/16 | 351 | Funny Bit | |
1/2 | 2 3/4 | 531 | ||
2 15/16 | 577 | |||
1 1/2 | 329 | |||
2 5/8 | 379 | |||
17/32 | 1 13/16 | 579 | ||
2 11/16 | 4010 | |||
9/16 | 1 5/8 | 447 | ||
1 7/8 | 581 | |||
2 5/16 | 209 | |||
2 3/8 | 211 | |||
2 5/8 | 229 | |||
2 15/16 | 233 | |||
3 | 245 | |||
2 11/16 | 397 | |||
19/32 | 2 13/16 | 595 | ||
5/8 | 1 7/8 | 231 | ||
2 1/8 | 549 | |||
2 5/8 | 223 | |||
2 3/4 | 521 | |||
2 13/16 | 70161 | |||
21/32 | 2 13/16 | 247 | ||
3 | 557 | |||
3 1/16 | 722 | |||
11/16 | 2 1/2 | 551 | ||
2 5/8 | 241 | |||
2 3/4 | 583 | |||
2 3/4 | 589 | Split Saddle | ||
2 7/8 | 601 | Top Hole P-Lip | ||
2 15/16 | 561 | Flat Sided Saddle | ||
3 | 529 | |||
3 1/8 | 671 | |||
23/32 | 2 15/16 | 511 | ||
3 1/16 | 615 | |||
3 1/16 | 635 | Angled Saddle | ||
3 1/8 | 519 | |||
3/4 | 3 1/16 | 243 | ||
25/32 | 3 1/16 | 733 | ||
3 5/16 | 627 | |||
3 7/16 | 239 | |||
7/8 | 2 11/16 | 527 | ||
3 1/2 | 810 | |||
15/16 | 2 11/16 | 449 | ||
Fancy | ||||
1 5/32 x 1 | 2 7/16 | 713 | Funny Triangle | |
19/32 | 2 1/2 | 481 | Flush Mount | |
3 1/16 | 449 | |||
3 1/8 | 485 | |||
3 1/8 | 603 | |||
23/32 | 3 3/16 | 493 | Flush Mount | |
3 5/16 | 427 | |||
1/2 | 3 3/8 | 473 | Flush Mount | |
9/16 | 3 3/8 | 429 | Flush Mount | |
23/32 | 3 7/16 | 431 | Flush Mount | |
3 1/2 | 347 | P-Lip | ||
19/32 | 3 9/16 | 471 | Flush Mount | |
3/4 | 3 11/16 | 735 | ||
3 11/16 | 777 | |||
3 3/4 | 487 | |||
13/32 | 3 13/16 | 489 | ||
3 7/8 | 441 | |||
3 7/8 | 399 | P-Lip | ||
17/32 | 4 | 661 | P-Lip, 9 mm Filter Hole | |
4 3/16 | 491 | |||
4 5/16 | 433 | P-Lip | ||
5 5/8 | 361 | 1/4 ÌÕ Rough Tenon | ||
- | 4 | 391 | ||
Oval Taper | ||||
15/32 x 5/8 | 1 11/16 | 395 | ||
15/32 x 21/32 | 2 5/8 | 573 | ||
15/32 x 11/16 | 1 5/16 | 8005 | ||
1/2 x 5 8 | 2 3/4 | 419 | ||
1/2 x 21/32 | 1 15/16 | 571 | ||
1/2 x 3/4 | 2 15/16 | 607 | ||
1/2 x 1 | 2 3/4 | 717 | ||
11/16 x 31/32 | 2 3/4 | 539 | ||
17/32 x 3/4 | 2 3/4 | 629 | ||
17/32 x 31/32 | 2 3/4 | 417 | ||
7/16 x 5/8 | 2 13/16 | 457 | ||
9/16 x 23/32 | 1 7/8 | 515 | ||
Oval Saddle | ||||
15/32 x 5/8 | 1 13/16 | 613 | ||
15/32 x 25/32 | 1 11/16 | 415 | ||
15/32 x 13/16 | 2 5/8 | 435 | ||
15/32 x 27/32 | 1 13/16 | 467 | ||
2 1/8 | 469 | |||
1/2 x 15/16 | 2 1/4 | 439 | ||
5/8 x 7/8 | 2 11/16 | 537 | ||
5/8 x 1 | 2 1/4 | 609 | ||
5/8 x 1 | 2 3/4 | 611 | ||
21/32 x 27/32 | 2 9/16 | 585 | ||
23/32 x 27/32 | 2 5/8 | 501 | ||
1/2 x 1 | 2 3/16 | 727 | ||
1/2 x 25/32 | 2 15/16 | 497 | ||
Diamond Taper | ||||
1/2 | 2 15/16 | 259 | ||
3 1/2 | 267 | |||
17/32 | 2 7/8 | 76141 | ||
19/32 | 3 | 289 | ||
Diamond Saddle | ||||
1/2 | 2 7/8 | 261 | ||
17/32 | 2 9/16 | 281 | ||
9/16 | 2 3/4 | 71141 | ||
2 7/8 | 287 | |||
2 7/8 | 5004 | |||
3 | 277 | P-Lip | ||
19/32 | 2 1/8 | 263 | ||
2 3/4 | 271 | |||
2 3/4 | 273 | |||
3 3/16 | 729 | |||
11/16 | 3 3/16 | 265 | ||
Square Tapers | ||||
19/32 | 3 1/16 | 621 | ||
21/32 | 2 7/8 | 283 | ||
Square Saddle | ||||
17/32 | 2 3/4 | 285 | ||
11/16 x 13/16 | 2 9/16 | 545 | ||
9/16 | 3 | 719 |
